特点：
2.该机采用先进的双层共挤的模头结构，制品平整，均匀度好，保证了包装、印刷等后续工序设备对薄膜的质量要求，适合生产复合珠光膜，复合液体包装膜，绝缘膜，多功能农用薄膜等。其运用范围正在逐步扩大，是塑料制品开发的方向。1.该机通过二台挤出机将两种相同或不同的物料塑化挤入共挤复合机头，生产出经共挤成型号的复合薄膜，从而大提高了薄膜的物理性能，增加其强度，使薄膜具有良好的阻隔性、气密性。
Features:
1.The machine extrudes two kinds of same or different materials into the co-extrusion die by two extruders, and produces the co-extrusion composite film, which greatly improves the physical properties of the film, increases its strength, and makes the film have good barrier and airtightness.2. The machine adopts advanced die structure of double-layer co-extrusion. The product is smooth and uniform. It guarantees the quality requirement of the film in the follow-up process such as packaging and printing. It is suitable for producing compound pearlescent film, compound liquid packaging film, insulation film, multi-functional agricultural film and so on. The scope of its application is gradually expanding, and it is the development direction of plastic products.
主要技术参数
Main technical parameters| 型号 TYPE |
YF-700 | YF-800 | YF-1000 | YF-1200 | YF-1400 |
| 适用原料 Applicable materials |
HDPE/LDPE/LLDPE | ||||
| 螺杆直径 Screw diameter（mm） |
Ø45×2 | Ø45×2 | Ø50×2 | Ø55×2 | Ø60×2 |
| 螺杆长劲比 Screw length ratio |
1:28 | 1:30 | 1:30 | 1:30 | 1:30 |
| 主电机功率 Main motor power（kw） |
11KW×2 | 11KW×2 | 15KW×2 | 18.5KW×2 | 22KW×2 |
| 最高挤出量 Maximum extrusion（kg/h） |
55kg/h | 65kg/h | 85kg/h | 110kg/h | 130kg/h |
| 产品最大宽度 Product width（mm） |
600mm | 700mm | 900mm | 1100mm | 1300mm |
| 产品厚度 Product thickness（mm） |
0.015-0.20 | 0.015-0.20 | 0.015-0.20 | 0.02-0.20 | 0.02-0.20 |
| 螺杆转速 Screw speed （r/min） |
10-100 | ||||
| 外形尺寸 Outline dimension (m) |
4.5*4*5.6 | 4.5*4*5.8 | 5.4*5*6.2 | 6*5.5*6.8 | 6.5*6*7.5 |
由于不断研究改进，我司保留改变设计之权利。
Due to continuous improvement, we reserve the right to change design.
